Features
- Readability: 0.1℃
- 7'inch HD color touch screen, display melting curve in real time
- Touch screen with intuitive operation
- Quickly and efficiently support auto test
- Unique digital temperature control technology with high accuracy
- Wider ramp rate with stepless speed
- Capillary tubes method conforms to pharmacopoeia
- Multiple points temperature calibration
- USB/RS232 can communicate with computer and printer
- Auto generate and store measuring report
- Up to 32 groups of preset measuring methods which help set working parameter quickly
- Two grades of user management. Support to edit passwords and multiple permission settings.
Technical Specifications
MAIN SPECIFICATIONS | |
| MODEL | Sgtk-2A |
| Test Method | Fully automatic |
| Sample Loading Way | Capillary Tube Method |
| Temperature range | Ambient ~400℃ |
| Min. Temperature Resolution | Ramp Rate |
| Stepless setting at | 0.1℃~20℃/min |
| Ramp Rate Error | ≤5% |
| Accuracy | ±0.2℃（﹤200℃）±0.4℃（≥200℃） |
| Reproducibility | 0.1℃（ramp rate 0.2℃/min） 0.2℃（ramp rate 1℃/min |
| Heating/Cooling time | ≈4mins/4mins |
| Number of Capillaries | 1 |
| Capillary dimensions | Φ1.4mm outside dia., Φ1.0mm inside dia., 90mm lengths. |
| Fill height | 3mm~5mm |
| Display | 7" HD Colour touch screen，1024×600 |
| Screen | display melting curve in real time |
| Communication interface | USB communication port，RS232printing port，USB port to export data |
| Print Function | Included |
| Measurement Report | Auto generate and store. Or store in PC via APP |
| User Management | Two grades：administrator+operator |
| Power supply | 110/220±10%V AC，50/60Hz/120W |
| Dimensions (L ×W×H) | 345X245X215mm |
| Weight | About 4.5kg |
