Features
- Portable and compact design
- Elastic structure hot lid design, adaptable to 96-well microplate or 0.1 /0.2ml PCR tube;
- Using high-quality peltier, ensure excellent temperature uniformity;
- The heating and cooling rate can reach to 5.5°C/s, saving experimental time;
- Humanized standard program file template, which can quickly edit experimental files;
- Automatic fault detection and alarm function.
Technical Specifications
| Model | TCG96S | TCG96G |
| Temp mode | Standard | Gradient |
| Sample capacity | 96×0.1/0.2mL PCR tube/96-wells microplate | |
| Block temp control range | 4~105°C | |
| Hot lid temp control range | 30~110°C | |
| Temp display accuracy | ±0.1°C | |
| Temp control accuracy | ±0.3°C | |
| Temp uniformity | ±0.3°C | |
| Max temp change rate | 5°C/s | |
| Gradient setting range | / | 30~105°C |
| Gradient span | / | 1~42°C |
| Heating module material | Aviation aluminum | |
| Display | 7-inch color touch screen | |
| User defined file storage | 676 files | |
| Power outage protection | Yes | |
| Voltage/Frequency | 100~240V;50/60Hz | |
| Dimension | L270×W240×H150mm | |
| Weight | 4.8kg | |
